    Gigabit Color IP Phone UUC862

    Manufacturer: ΗΤΕΚ
    Htek UC862 Gigabit Color IP Phone
    SKU: 09.217.0332
    Availability: Out of Stock - on backorder and will be dispatched once in stock.
    €167.40
    i h

    UC862 is an innovative enterprise-level Color IP Phone that features 4 Line keys, 10 programmable extension keys, 3.5” TFT-LCD with 480*320 pixel. It supports up to 5-way conference. UC862 is optimized for executive use for major decision makers, administrative assistants and those working with bandwidth-intensive application on collocated PCs. 10 programmable extension keys could be configured as IP PBX features like BLF, SCA, Intercom, Call Pickup, Call Park and many other features. The high-resolution TFT-LCD and HD Voice bring you the lifelike visual and hearing experience.

    Features

    • 3.5”TFT-LCD, 480 x 320 pixel, 262K colors
    • Dual-port Gigabit Ethernet ports
    • 4 VoIP accounts
    • Multi-language
    • 47 keys including 14 programmable keys
    • Support Power over Ethernet(PoE)
    • Support Auto-provision via TFTP / FTP / HTTP /HTTPS

    Physical Feature

    • 3.5”TFT-LCD, 480 x 320 pixel, 262K colors
    • Ethernet: Dual-port Gigabit Ethernet ports
    • Keys: 47 keys including 14 programmable keys
    • WAN Port: 10/100/1000 RJ-45 for Internet
    • LAN Port: 10/100/1000 RJ-45 for PC
    • Handset: 1 RJ9(4P4C)
    • Headset: 1 RJ9(4P4C)
    • CPU: 600M
    • Adapter output: 5V/1.2A
    • Adapter input: 100-240V
    • Power consumption: standby - 2.2W / working - 2.4W
    • Power over Ethernet(PoE): IEEE 802.3af (Optional)
    • Operation temperature: -10 ~ 50?
    • Relative Humidity: 10 ~ 95%
    • Weight - Phone: 0.74kg
    • Dimension: (W*D*H*T): 290*210*125mm

    VoIP Protocol

    • SIPv2, SDP(RFC 2327), RTP(RFC 1889,1890), RTCP
    • RFC 2833 X-NSE Tone Events for SIP/RTP, AVT Tone
    • Events for SIP/RTP

    Voice Codecs

    • HD wideband codec:
    • G.722. HD Codec, HD speaker, HD handset
    • Full-duplex speakerphone with AEC
    • G.711 µ-law/A-law, G.723.1, G.726, G.729A/B.
    • DTMF(In-Band, RFC2833, SIP Info)
    • Acoustic Echo Cancelation(AEC)
    • Acoustic Gain Control(AGC)
    • Voice Activity Detection(VAD), Comfort Noise insertion

    Security

    • HTTPS Server/Client
    • Transport Layer Security (TLS)
    • SRTP (RFC3711), SIPS
    • VLAN QoS (802.1pq)

    Telephone Interfaces

    • 4 VoIP Accounts
    • Menu-driven user interface, XML Idle Screen, Theme
    • Screen Sleep
    • Call hold, Call waiting, Call forward, Call return
    • Redial,Call transfer
    • Caller ID display, DND, Auto-answer, 5-Way Conference
    • Mute, Speed dial, SMS, Voicemail, Message Waiting
    • Indication (MWI) LED, Call history
    • BLF/BLA
    • Hot-desking, Tone scheme, Volume control
    • Ring tone selection/Import/Delete
    • Broad and Deep Interoperability
    • Soft keys programmable
    • Phonebook, Black list XML/LDAP phonebook

    Network Protocol

    • TCP, UDP, ICMP, RARP, ARP, DNS, NTP,SNTP, STUN, UPnP,SNMP
    • Static/DHCP/PPPoE
    • TFTP/DHCP/PPPoE client

    HTTP/HTTPS server
