Storage Device | 2.5" SATA-II SSD 64GB (default) or HDD 320GB (optional) |
Memory | Single-Channel DDR3 Connector for 1066/800MHz x 1, default 2GB up to 4GB |
Graphics | Intel Graphics Media Accelerator 3600 | Intel HD Graphics (350MHz-1GHz) |
BIOS | AMI BIOS |
OS | POS Ready2009, POS Ready 7 |
Main Display | 15" with WLED Backlight (1024 x 768), Single LVDS 24bits Supports 5-Wired Resistive Flat or Normal Type Touch Panel Supports Tilt (0? ~ 53?) 10°-60° Viewing Angle, 300:1 Contrast, Above 350cd/m2 Brightness |
LAN | 1 x 10/100/1000Mbps Base T Ethernet |
Serial Port | 2 x DB9 and 1 x RJ50 Serial Ports, Powered on Pin 9 (DC+5V or DC+12V) |
USB | 6 x USB A type 2.0, 1 x mini USB B type 2.0 |
Special USB | 1 x mini USB type A, B |
VGA | D-SUB 15 pin Analog VGA port |
Cash Drawer | 1 x RJ11 (12V) on the Right Rear Side |
Audio Ports | 1 x Mic-in, 1 x Audio-out |
Speaker Out | 1watt Speaker (Stereo) X 2EA |
Expansion Slot | miniPCI-e |
2nd Display | 10" or 15 with WLED back light (1024 x 768), Single LVDS 24bit or 18bit Support 5-wired resistive touch panel (optional) Support tilt (15? ~ 45?) and swivel : 25? 10°-60° Viewing Angle, 300:1 Contrast, 300cd/m2 Brightness |
Customer Display | VFD Type (20 x 2), Alphabet & Numeric, Supports 15° – 90° Tilt and 25° Swivel |
Touch Panel | Support 5-wired resistive Flat Touch panel |
MSR | ISO7811, All Track USB (default) and Serial (CMOS setting) interface Bi-Directional reading, min. 1million times reading Card reading speed 3inch to 60inch/sec |
Smart Card Reader | ISO7816 EMV level 1 |
Dallas Reader | Supports PC/SC(Personal Computer/Smart Card) |
Dimensions | 354 x 246 x 339 (W x D x H, mm) |
Weight | 5.5 (Kg) |
Color | White & Black |
Power Supply | 100V AC ~ 240V AC, DC12V-5A Adaptor, 60 watt |
Temperature | Operating: 0 ~ 40?C, Storage: 0 ~ 60?C |
Humidity | 10 ~ 80% Humidity |
