| Printing Technology |
Direct Thermal |
| Print Speed (maximum) |
200 mm /sec.
|
| Print Width (maximum) |
104 mm |
| Media Width (min to max) |
58 - 112 mm |
| Media Thickness (min to max) |
65 to 150 μm |
| Media Sensor |
Gap, reflective black mark and paper end |
| Roll Size (max), Core Size |
102 mm outside diameter |
| Case |
|
| Control panel |
1 button, 2 LEDs |
| Flash (Non-Volatile Memory) |
384K bytes |
| Drivers and software |
Free-of-charge from website, including support for various platforms |
| Size (W x D x H) and Weight |
170 x 216 x 151 mm, 2.5 Kg
|
| Warranty |
2 years including head and cutter |
| Emulations (Languages) |
ESC/POS™
|
| Barcodes |
- UPC-A
- UPC-E
- EAN-13 (JAN-13)
- EAN-8(JAN-8),
- Codabar, ITF
- CODE39
- CODE128
- CODABAR(NW-7)
- CODE93
- PDF 417
- QR Code
- GS1-Databar
- Composit Symb
- Code3of9
|
| Media type |
Thermal labels + receipt paper |
| Cutter |
Guillotine type, full and partial |
| Drawer kick-out |
2 Drawers |
| Power supply |
100 - 240V, 50/60hz |
| EMC and safety standards |
|
| Number of columns |
- On 112mm paper up to 69 digits (12 x 24 font A)
- On 112mm paper up to 104 digits (8 x 16 font C)
- On 112mm paper up to 92 digits (9 x 17 font B)
|
| Character table / Code page |
- Alphanumeric
- International characters
- Kana
- Kanji (JIS level 1, level 2)
- Katakana
- Thai code18
- WPC1252
- 437
- 850
- 852
- 857
- 858
- 860
- 863
- 864
- 865
- 866
|
| Input buffer |
4K bytes / 45 bytes |
| Operation environment |
+5 to +40°C, 35% - 90% RH, non condensing |
| Storage environment |
-20 to +60°C, 10% - 90% RH, non condensing |
| Paper sensor |
|
| Blackmark sensor |
Black mark sensor (Photo interrupter) |
| Code pages |
15 codepages, 17 country tables |
| Resolution |
203 dpi
|
| Main Interface |
USB 2.0 full speed |
| Interface |
- Bluetooth with Apple™ MFi compatibility
- Serial (RS-232C compliant)
- Compact Wireless LAN
- Ethernet
- USB with hub
|
